1/14 Armageddon FMX RC Hydraulic Dump Truck 8x8
- Eagle Machinery
- Model Number:
- Package Type:
- Carton With Foam
Email us at Eaglemach@foxmail.com if assistance needed!
Upgraded New FMX 2.0 Version!
1.Truck Left Side: Includes Urea Tank,Battery Box;
2.Truck Right Side: Add Exhaust Pipe;
3.Radio Control Upgrades Into 10Channel One.
4. Battery Would Be Put Under Bucket To Enlarge The Compartment Size
5.Dumping Bucket Upgrades
The Difference Between Man And Boy
1:14 Scale / Full Metal / Ready-to-Run / Battery Powered
New 2.0 Version hydraulic dump truck 8x8,upgraded with highly scaled and detailed FMX truck cab
and dump bucket,meanwhile,retained the features of old JD-2 Dump Truck-Excellent climbing ability,
heavy load ability and Highly detailed base on European style dump truck. Engineered specifically for the tough demands of transporting gravel,sand,asphalt, snow,wood chips or rocks.Created for the customer who requires reliability and high production in bulk earth moving or construction projects.CNC machined metal parts,fully assembled,ready to work! Massive power through 1000kV high speed brushless system.
- Hard ABS European style front Cab
- Full metal 2 speed transmission (Planetary gears)
- European style V shape dumper
- Engine sound system installed(Sound Module Version Only)
- Transfer case (billet alum)
- Scale fuel tank (billet alum)
- Super scaled leaf spring suspension setup
- Scale rims (billet alum)
- Remote lockable rear axle (locking differential)
- Full metal front and rear axle housing
- Steel scale drive shaft
- Realism front cab latch
- Retractable steel ladder
- Molded functional fuel tank (filled with hydraulic oil)
- Automatic trailer gate (do not attempt to open it by hand)
- Retractable steel ladder
- Rear light guard (protect against rock)
- Scale light bucket (fit 3-5mm LED)
- Recommended payload: 16kg/35lbs
- Maximum lift power: 42kg/92lbs
- Fully painted
- Scale fire extinguishers and spare wheel/tire
- Cylinder maximum thrust: 109kg/231 lbs
- Brushed driven motor
- 1000kV Brushless motor-driven micro hydraulic pump
- Length: 687mm/27inch
- Width: 186mm/7.3inch
- Height: 262mm/10.3inch
- Weight: 8kg/17lbs
- Axle gear ratio: 2.6:1
- Transfer case gear ratio: 1:1
- Theoretical load: 15kg/33lbs
- Load total mass: 23kg/50lbs
- First gear 1:16, second gear 1:4 (Transmission)
- Basic 6 channel 2.4Ghz radio
- Basic 60T 540 motor
1. Do not operate before signal confirmation finish!!! (First turn on the RC control,all joystick on up position,then connect machine power,after 4 sounds signal confirmation(about 5 seconds),then operate!
2. Do not change radio controller factory default setting!!!
New Orange Color(US$100 Extra)
Free Shipping/Post Shipping Time: 15-30Days.
